M1002S223 16.666600|MP-1|晶振|±30 ppm,编码M1002S223 16.666600,型号MP-1,SMD晶振,MTRONPTI晶振,频率为16.666600MHZ,负载电容为14PF,精度±30ppm,尺寸HC-49U,温度范围:-40℃-85℃, 石英晶体谐振器,无源晶振,插件晶振,广泛的应用于倒车雷达,行车记录仪,mp3,mp4,mp5,蓝牙耳机,充电宝,电脑,电视,打印机等.
M1002S223 16.666600|MP-1|晶振|±30 ppm
| 型号 | MP-1 |
| 频率范围 | 16.6666MHZ |
| 负载电容 | ±20PF |
| 精度 | ±30PPM |
| 工作温度 | -40℃-85℃ |
| 存在温度 | -55℃-125℃ |
M1002S223 16.666600|MP-1|晶振|±30 ppm
| 物料编码 | 型号 | 频率 | 精度 | 尺寸 | 工作温度范围 | 负载电容 |
| M13252JM 24.000000 | M1325 Series | 24 | ±30 ppm | 3.2 x 5.0 mm | -40?C to +85?C | 18 pF |
| M13804MP 15.000000 | 圆柱晶振 | 15 | ±50 ppm | 3.7 x 8.0 mm | -55?C to +125?C | 20 pF |
| M15322GZL 0.032768 | M1532 Series | 0.0328 | ±20 ppm | 1.5 x 3.2 mm | -40?C to +85?C | 18 pF |
| PM2DF13 25.000000 | PM series | 25 | ±10 ppm | 5.0 x 7.0 mm | -40?C to +85?C | 18 pF |
| PM2FM10 25.000000 | PM series | 25 | ±15 ppm | 5.0 x 7.0 mm | -40?C to +85?C | 18 pF |
| PM2JM 10.000000 | PM series | 10 | ±30 ppm | 5.0 x 7.0 mm | -40?C to +85?C | 18 pF |
| PM2MM 20.000000 | PM series | 20 | ±50 ppm | 5.0 x 7.0 mm | -40?C to +85?C | 18 pF |
| PM3MM 11.059200 | PM series | 11.0592 | ±50 ppm | 5.0 x 7.0 mm | -55?C to +105?C | 18 pF |
| PM3MM 24.000000 | PM series | 24 | ±50 ppm | 5.0 x 7.0 mm | -55?C to +105?C | 18 pF |
| PM3MM 30.000000 | PM series | 30 | ±50 ppm | 5.0 x 7.0 mm | -55?C to +105?C | 18 pF |
| PM4GM 25.000000 | PM series | 25 | ±20 ppm | 5.0 x 7.0 mm | -55?C to +125?C | 18 pF |
| PM4JM 20.000000 | PM series | 20 | ±30 ppm | 5.0 x 7.0 mm | -55?C to +125?C | 18 pF |
| PM4MM 27.000000 | PM series | 27 | ±50 ppm | 5.0 x 7.0 mm | -55?C to +125?C | 18 pF |
| M1002S209 4.000000 | MP-1 Series | 4 | ±20 ppm | HC-49U | -55?C to +105?C | 29.5 pF, 30 pF, 30.5 pF |
| M1002S210 5.482000 | MP-1 Series | 5.482 | ±20 ppm | HC-49U | -55?C to +105?C | 29.5 pF, 30 pF, 30.5 pF |
| M1002S223 16.666600 | MP-1 Series | 16.6666 | ±20 ppm | HC-49U | -40?C to +85?C | 14 pF |
| M1002S348 4.730880 | MP-1 Series | 4.7309 | ±30 ppm | HC-49U | -20?C to +70?C | 20 pF |
| M1002S350 3.686400 | MP-1 Series | 3.6864 | ±30 ppm | HC-49U | -20?C to +70?C | 30 pF |
| M1002S351 11.059200 | MP-1 Series | 11.0592 | ±30 ppm | HC-49U | -20?C to +70?C | 30 pF |
| M1002S358 2.048000 | MP-1 Series | 2.048 | ±30 ppm | HC-49U | -55?C to +105?C | 18 pF |
| M1002S362 8.760000 | MP-1 Series | 8.76 | ±50 ppm | HC-49U | -20?C to +85?C | 32 pF |
| M1002S366 3.200000 | MP-1 Series | 3.2 | ±30 ppm | HC-49U | -55?C to +90?C | 32 pF |
| M1002S367 11.059200 | MP-1 Series | 11.0592 | ±20 ppm | HC-49U | -55?C to +105?C | 18 pF |
| M1007S045 25.000000 | PM series | 25 | ±30 ppm | 5.0 x 7.0 mm | 0?C to +85?C | 20 pF |
| M1007S099 25.000000 | PM series | 25 | ±10 ppm | 5.0 x 7.0 mm | -40?C to +70?C | 18 pF |
